Professional One-Stop Light Therapy Solutions Manufacturer with Over 14 Years of Experience.
YD002 Versatile Fabric Red & Infrared LED Therapy Pad
- 120 High-Efficiency LEDs: 0.5W each, with a 1:2 ratio of 660nm Red to 850nm NIR.
- Multi-Mode Operation: All LEDs, Red Only, NIR Only & Pulsing options.
- Comfortable Fabric Design: Lightweight (0.58 kg) and flexible for various body parts.
- Potent & Safe: >100mW/cm² irradiance at 0 inch, 0 UT EMF.
- OEM Ready: Fully customizable (logo, shape, color, wavelength).
Experience Advanced Therapy with Unmatched Comfort & Versatility
The Power of Optimized Dual Wavelengths
The YD002 pad utilizes 120 specialized LEDs, each containing three chips: one 660nm Red light chip and two 850nm Near-Infrared (NIR) light chips. This precise 1:2 ratio delivers a balanced spectrum for comprehensive benefits.
- 660nm Red Light: Targets the skin surface to promote rejuvenation, reduce inflammation, and aid in superficial pain relief.
- 850nm Near-Infrared Light: Penetrates deeper into tissues to alleviate joint pain, muscle soreness, improve circulation, and support cellular repair. (Note: 850nm light is invisible to the human eye but is fully active).
Intuitive Multi-Mode Control for Tailored Sessions
Easily customize your therapy session with the YD002’s intuitive single-button control system:
Quick Press (Green Indicator):
- All LEDs (660nm + 850nm) ON.
- Red LEDs (660nm) ON only, NIR OFF.
- Near-Infrared LEDs (850nm) ON only, Red OFF.
- All LEDs OFF.
Long Press (3+ Seconds - Blue Indicator):
- All LEDs (660nm + 850nm) in PULSE mode.
- Red LEDs (660nm) only in PULSE mode.
- Near-Infrared LEDs (850nm) only in PULSE mode.
- All LEDs OFF.
Designed for Comfort, Portability & Targeted Application
Crafted from soft, flexible fabric, the YD002 contours to various body parts for targeted treatment. Its lightweight design (0.58KG) and support for power bank operation (output ≥ 5V 2A suggested) make it perfect for use at home, in the office, or while traveling. The included stretchy straps ensure secure and comfortable placement.
Premium Specifications, User-Friendly Design, Ready for Your Brand
Technical Specifications
| Feature | Specification |
|---|---|
| Model No. | YD002 |
| LED Quantity | 120 x 0.5W (Each LED: 1x660nm, 2x850nm chips) |
| Wavelengths | 660nm (Red) : 850nm (Near-Infrared) = 1:2 |
| Rated Power | 60W |
| Actual Power | 25W |
| Product Size | 40 x 20 x 0.5 cm |
| Net Weight | 0.58 KG |
| EMF Emission | 0 UT (Negligible) |
| Irradiance | >100 mW/cm² (at 0 inch) |
| Timer | 20 Minutes (Automatic) |
| Material | Fabric |
| LED Lifespan | Over 50,000 Hours |
| Power Supply | AC Adapter (included) or Power Bank (≥ 5V 2A, not incl.) |
| Warranty | 1 Year |
| Certifications | CE, ROHS, FDA |
| Package Size | 28.2 x 19.2 x 6.7 cm |
| Accessories | Red light therapy pad x1, Power cord x1, Adapter x1, Stretchy straps x1, Connecting wire x1, User Manual x1 |
| Customization | Logo / Shape / Color / Wavelength |
Simple to Use, Effective Results
Effortless Therapy for Daily Wellness
User Instructions Summary:
- Power Up: Connect to AC socket or suitable power bank (≥ 5V 2A).
- Placement: Apply directly to the treatment area (0-inch distance for best results) for joint pain or desired effect.
- Select Mode: Use the single button for desired light (All/Red/NIR) or pulse mode.
- Treatment Time: Device has a built-in 20-minute timer per session. Do not exceed 30 minutes on one treatment area.
- Frequency: Recommended daily use of 1-2 times for at least 4 weeks for optimal results. Move to the next treatment area after each session.
Important Notes:
- Device is not waterproof. Not for use by children or pregnant women.
- Maintain by continuing use several times a week.
Your Ideal OEM/ODM Partner: REDDOT LED
Customize the YD002 Pad to Fit Your Brand & Market
The YD002 offers an excellent platform for creating a unique product. Partner with REDDOT LED for comprehensive customization options:
Brand Integration:Custom logo printing on the pad, straps, and packaging.Tailored Design:Modify shape, size, or fabric color to meet specific market demands.Wavelength Adjustments:Explore different LED ratios or specific wavelength configurations.
Offer Flexible, Effective Light Therapy with the YD002 Pad
